For the repair of straight pipes from DN70 – DN375. Bespoke kits can be manufactured up to DN1200.
Available in 550mm and 1000mm lengths.
Available with summer or winter resin, for the best working and curing times for the ambient temperature. The following curing times and temperatures are based upon ambient conditions and are intended as a guide only:
| Winter Resin (W) | ||
| Temperature | Working Time (Mins) |
Curing Time (Mins) |
| 8ºC (33ºF) | 20-22 | 100-120 |
| 13ºC (55ºF) | 18-20 | 90-110 |
| 18ºC (64ºF) | 16-19 | 75-100 |
| 23ºC (73ºF) | 15-17 | 60-70 |
| 28ºC (82ºF) | 10-12 | 45-55 |
| 33ºC (91ºF) | 7-9 | 40-45 |
| Summer Resin (S) | ||
| Temperature | Working Time (Mins) |
Curing Time (Mins) |
| 8ºC (33ºF) | 45-48 | 150-300 |
| 13ºC (55ºF) | 41-45 | 130-150 |
| 18ºC (64ºF) | 32-35 | 120-135 |
| 23ºC (73ºF) | 30-32 | 90-100 |
| 28ºC (82ºF) | 20-23 | 70-85 |
| 33ºC (91ºF) | 14-16 | 65-75 |
For faster working and curing times, a Rapid kit can be purchased.
Product Range
| Code | Product Description |
| PD100KITS | DN100 Pipe Summer resin |
| PD100KITW | DN100 Pipe Winter resin |
| PD1M100KITS | DN100 pipe 1m Long Summer resin |
| PD1M100KITW | DN100 pipe 1m Long Winter resin |
| PD150KITS | DN150 Pipe Summer resin |
| PD150KITW | DN150 Pipe Winter resin |
| PD1M150KITS | DN150 Pipe 1m Long Summer resin |
| PD1M150KITW | DN150 Pipe 1m Long Winter resin |
| PD225KITS | DN225 Pipe Summer resin |
| PD225KITW | DN225 Pipe Winter resin |
| PD1M225KITS | DN225 Pipe 1m Long Summer resin |
| PD1M225KITW | DN225 Pipe 1m Long Winter resin |
| PD300KITS | DN300 Pipe Summer resin |
| PD300KITW | DN300 Pipe Winter resin |
| PD1M300KITS | DN300 Pipe 1m Long Summer resin |
| PD1M300KITW | DN300 Pipe 1m Long Winter resin |
| PD375KITS | DN375 Pipe Summer resin |
| PD375KITW | DN375 Pipe Winter resin |
| PD1M375KITS | DN375 Pipe 1m Long Summer resin |
| PD1M375KITW | DN375 Pipe 1m Long Winter resin |
